DevExpress Dashboard provides the capability to combine dashboard items into a group. The dashboard item group serves two main purposes.

•Combine dashboard items within the dashboard into a separate layout group.

•Manage interaction between dashboard items within and outside the group.

For instance, you can combine related filter elements and data visualization dashboard items into a group.

•Create a Group

•Interactivity

Create a Group

To create a new group, use the Group button in the Home ribbon tab.

You can add dashboard items to a group and manage item layout using drag-and-drop. To learn how to manage a group's caption, see the Dashboard Item Caption topic.

Note

Note that a dashboard item group cannot be added to another group.

Interactivity

The dashboard item group provides the capability to manage interaction between dashboard items within and outside the group.

The Master Filter button allows you to specify whether the current group allows you to filter external dashboard items using master filter items contained within the group. If this option is disabled, master filter items contained within the group can filter only dashboard items from this group.****

The Ignore Master Filters button allows you to isolate dashboard items contained within the group from being filtered using external master filter items.
